Schmersal 101056532 Position Switch 1NO-1NC Silver Contact

Product Code: 101056532

  • IP65 rated for dust and water protection
  • Complies with CE, IEC/EN60947-5-1 standards
  • Silver contacts for reliable performance
  • Screw terminals for secure connections
  • Durable with 5 million mechanical operations
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
441

Electrical

Rated Impulse Withstand Voltage (Uimp)
6kV
Rated Insulation Voltage (Ui)
500V
Switching Principle
Slow action / double break
Contact Configuration
1 NC + 1 NO
Mechanical Life
10,000,000 operations

Mechanical

Actuator / Operating Element
Rod/roller lever head without lever; brass roller

Dimensions & Physical Data

Depth
63
Height
99
Weight
1.594kg
Width
106

Safety, Standards & Compliance

Standards and Approvals
CCC
