Schmersal 101055844 Magnetic Reed Switch 1m L Cable 0.5A BP 10 Cable Terminal

Product Code: 101055844

  • Rated for 250 VAC, 0.5 A
  • IP67 protection for harsh conditions
  • Operates in -25 to 75°C range
  • Durable with 1 billion operations life
  • Magnetic drive switching with reed contacts
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Magnetic Reed Switch
Brand
Schmersal
Series
BN 80

Electrical

Configuration Type
Normally open contact (NO)
No. of N/C Contacts
0
No. of N/O Contacts
1
Switching Current
0.5A
Switching Voltage
250V AC, 250V DC
Electrical Connection
Pre-wired cable

Mechanical

Material
Glass-fibre, reinforced thermoplastic

Dimensions & Physical Data

Depth
9mm
Height
13mm
Weight
0.024kg
Width
44mm
Cable Length
1m

Environmental

Operating Temperature
-25°C to 75°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
