Schmersal 101031672 Safety Hinge Switch 1NO+1NC

Product Code: 101031672

  • Rated current of 1500 mA for reliable operation
  • Durable with 3 million mechanical cycles
  • Roller lever actuator for precise control
  • Compact size: 30mm W x 85mm H x 60mm D
  • IP67 protection for harsh environments
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Hinge Switch
Brand
Schmersal
Series
TESZ

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
1
Rated Current (In)
2A, 1A
Rated Voltage (Ur)
230V AC, 24V DC
Terminal Type
Screw terminals

Mechanical

Cable Entry
2 x M20 x 1.5
Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
36mm
Height
92mm
Weight
0.467kg
Width
111.5mm

Environmental

Operating Temperature
-25°C to 65°C
IP Rating
IP65

Documents

IPD Product Catalogue V17
