Schmersal 101029153 Safety Hinge Switch 1NO+1NC

Product Code: 101029153

  • Rated for 500 mA current
  • Roller plunger actuator type
  • Durable with 10M mechanical cycles
  • IP67 protection for harsh environments
  • Operates from -25 to 80°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Hinge Switch
Brand
Schmersal
Series
TESZ1102/S

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
1
Rated Current (In)
2A (AC) / 1A (DC)
Rated Voltage (Ur)
230V AC / 24V DC
Terminal Type
Screw terminals

Mechanical

Actuator Type
Hinge actuator
Cable Entry
2 x M20 x 1.5
Housing Material
Glass-fibre reinforced thermoplastic

Dimensions & Physical Data

Depth
36mm
Height
92mm
Weight
0.28kg (approximate)
Width
111.5mm

Environmental

IP Rating
IP65
Ambient Temperature
-25°C to 65°C
