Product Code: PAXD0110

Versatile 24VAC/11-36VDC power options
Clear 4-digit green LED display
Compact 0.56-inch panel mount design
Reliable in 0 to 50°C environments
Complies with CE, CSA, and UL standards

Specifications

General

Product Type

Universal DC Input Panel Meter

Brand

Red Lion

Series

PAX

Electrical

Analog Resolution 16 bit	Channel Isolation 500 V AC	Digital Inputs 3
Digital Outputs 0	Analog Outputs 0	Input Ratings ±200 mV DC, ±2 V DC, ±20 V DC, ±300 V DC, ±200 µA DC, ±2 mA DC, ±20 mA DC, ±200 mA DC, ±2 A DC
Input Type DC voltage, DC current	Power Consumption 11 W at 11 to 36 V DC, 15 VA at 24 V AC	Supply Voltage 11 to 36 V DC, 24 V AC
Terminal Type High-compression cage-clamp	Analog Inputs 1

Mechanical

Housing Material

Polycarbonate

Dimensions & Physical Data

Depth

104.1mm

Height

49.5mm

Width

96.5mm

Environmental

Storage Temperature

-40°C to 60°C

Operating Temperature

0°C to 50°C

IP Rating

IP65

Communication & Control

Ethernet Ports 0	Expandable Communications Yes	Fieldbus Interface DeviceNet, PROFIBUS-DP
Serial Ports 0	USB Port 0	Supported Serial Protocols RLC Protocol (ASCII), Modbus RTU, Modbus ASCII

Safety, Standards & Compliance

Certifications / Approvals

CE, EN 61326-1, EN 61010-1, EN 61010-2-030, RoHS, UKCA, UL E179259

Accessories & Additional Information

Development Software

Crimson

RED LION PAX SERIES PANEL METE R PAX SERIES PANEL METER
