Product Code: E3-MIX24880-1

Operates on 10-30 VDC power.
Consumes 355 mA current.
Easy DIN Rail mounting.
CE, CSA, EN61010-1, UL508 approved.

Specifications

General

Product Type

Rugged High-Density I/O Modules

Brand

Red Lion

Series

E3 I/O Modules

Electrical

Digital Inputs 24	Digital Outputs 8	Output Ratings 0.6A per channel
Input Ratings 10K Ohm (DI) / 100 Ohm (AI)	Input Type Mixed DI / 4-20 mA	Output Type 10-30 VDC Sourcing
Supply Voltage 10-30 VDC	Terminal Type Screw Terminals	Analog Inputs 8

Mechanical

Housing Material

Hardened metal enclosure

Mounting Method

DIN-Rail

Dimensions & Physical Data

Depth

72.4 mm

Height

134.6 mm

Width

142.2 mm

Environmental

Storage Temperature

-40 to 85 °C

Operating Temperature

-40 to 75 °C

IP Rating

IP54

Communication & Control

Ethernet Port Speed 10/100 Mbps	Ethernet Ports 2	Fieldbus Interface Modbus and Sixnet protocols
Serial Ports 1	USB Port 1	Supported Ethernet Protocols TCP/IP, ARP, UDP, ICMP, DHCP, HTTP, Modbus TCP/UDP (master or slave), Sixnet TCP/UDP (master or slave)
Supported Serial Protocols Sixnet UDR and Modbus RTU/ASCII

Safety, Standards & Compliance

Compliance Standards

UL 508, CSA C22.2/142, IEC 61010-1, CE, FCC part 15, ICES-003, Class A, ABS, DNV, Lloyds

Hazardous Location Ratings

Class I, Division 2, ATEX/IECEx Zone 2

Accessories & Additional Information

Development Software

Crimson 3.0

Red Lion E3-MIX24880-1 I/O Module 10-30VDC DIN Rail
