Product Code: E3-16DIAC-1

Supports 24/120 VAC/DC input
DIN Rail mounting for easy installation
Operates in -40 to 75°C range
CE, UL/cUL Class 1 Div 2 approved
High precision with 16-bit A/D resolution

Specifications

General

Product Type

Rugged High-Density I/O Modules

Brand

Red Lion

Series

E3 I/O Modules

Electrical

Channel Isolation 150V (individually isolated)	Digital Inputs 16	Input Ratings 60-140 VAC range
Input Type 120 VAC nominal	Supply Voltage 10-30 VDC	Terminal Type Screw Terminals

Mechanical

Housing Material

Hardened metal enclosure

Mounting Method

DIN-Rail

Dimensions & Physical Data

Depth

72.4 mm

Height

134.6 mm

Width

142.2 mm

Environmental

Storage Temperature

-40 to 85 °C

Operating Temperature

-40 to 75 °C

IP Rating

IP54

Communication & Control

Ethernet Port Speed 10/100 Mbps	Ethernet Ports 2	Fieldbus Interface Modbus and Sixnet protocols
Serial Ports 1	USB Port 1	Supported Ethernet Protocols TCP/IP, ARP, UDP, ICMP, DHCP, HTTP, Modbus TCP/UDP (master or slave), Sixnet TCP/UDP (master or slave)
Supported Serial Protocols Sixnet UDR and Modbus RTU/ASCII

Safety, Standards & Compliance

Compliance Standards

UL 508, CSA C22.2/142, IEC 61010-1, CE, FCC part 15, ICES-003, Class A, ABS, DNV, Lloyds

Hazardous Location Ratings

Class I, Division 2

Accessories & Additional Information

Development Software

Crimson 3.0

Red Lion E3-16DIAC-1 I/O Module 24/120VAC/DC DIN Rail 16 Inputs
