Product Code: DAM00PDP2S000000

Efficient 2.7 W power usage
Easy DIN rail installation
IP30 protection for safety
Complies with EN61326-1 standards

Specifications

General

Product Type

Pid Control Module

Brand

Red Lion

Series

FlexEdge

Electrical

Channel Isolation 500 Vrms isolation between circuits	Digital Outputs 4 Solid-State NFET outputs	Output Ratings NFET: 1 A max, 30 VDC max, Vds_on ˜ 0.3V @ 1 A
Input Ratings TC input impedance 20 MO; RTD 150 µA; process input 10 V / 20 mA range	Input Type Thermocouple, RTD, mV, 0–10 V, 0/4–20 mA	Output Type Solid State NFET
Power Consumption 2.7W	Terminal Type Screw terminals	Analog Inputs 2 Signal input

Mechanical

Housing Material

Metal + Plastic

Dimensions & Physical Data

Depth

157.91mm

Height

114.97mm

Width

34.32mm

Environmental

Storage Temperature

-40°C to 85°C

Operating Temperature

-40°C to 75°C

IP Rating

IP30

Communication & Control

Expandable Communications

Provided by host DA70 Controller

Safety, Standards & Compliance

Hazardous Location Ratings

Class I Division 2, ATEX, IECEx

Certifications / Approvals

CE, EN 61326-1, IEC/EN 61010-1, RoHS Compliant

Accessories & Additional Information

Development Software

Crimson

Red Lion DAM00PDP2S000000 SSR Output Module 1 Output
