Product Code: DAM00I02C0000000

Efficient 2 W power consumption
Easy DIN rail mounting
IP30 protection rating
Complies with EN61326-1 standards

Specifications

General

Product Type

High - Speed Rate Counter Module

Brand

Red Lion

Series

FlexEdge

Electrical

Channel Isolation 500 Vrms isolation for inputs; channel-to-channel isolation	Digital Inputs 8	Digital Outputs 8
Output Ratings 1 A max, 30 VDC max, Vds(on) < 0.2 V @ 1 A	Input Ratings Max input voltage: 30 VDC; ON ≥ 2.5 V; OFF ≤ 1.5 V	Input Type Sinking/sourcing; TTL compatible; max 30 VDC; software debounce optional
Output Type N-channel open-drain MOSFET outputs	Power Consumption 2W	Terminal Type Screw terminals

Mechanical

Housing Material

Plastic

Dimensions & Physical Data

Depth

34.32mm

Height

157.91mm

Width

114.97mm

Environmental

Storage Temperature

-40°C to 80°C

Operating Temperature

-40°C to 75°C

IP Rating

IP30

Communication & Control

Expandable Communications

Provided by host DA70 Controller

Safety, Standards & Compliance

Hazardous Location Ratings

II 3 G Ex ec IIC T4 Gc ( ATEX )

Certifications / Approvals

CE, EN 61326-1, IEC/EN 61010-1, RoHS Compliant

Accessories & Additional Information

Development Software

Crimson 3.2

Red Lion DAM00I02C0000000 High Speed Rate Counter Module 6 Inputs 8 Outputs
