Specifications

General

Product Type

Miniature Intelligent Meter

Brand

Red Lion

Series

CUB5RT

Electrical

Input Ratings Red (max intensity) 85 mAGreen (max intensity) 95 mA	Input Type Current	Supply Voltage 9 - 28 VDC
Terminal Type Screw Terminals

Mechanical

Housing Material High impact plastic case	Mounting Method Panel Mounting	Display Colour/Type Red/Green
Display Lines 1

Dimensions & Physical Data

Depth 47.2 mm	Height 39.1 mm	Width 74.9 mm
Panel Cut-Out Size 68 W mm x 33 H mm	Display Size 5 digit LCD 0.48" (12.2 mm) high digits

Environmental

Storage Temperature

-35 to 85 °C

Operating Temperature

INTENSITY LEVEL TEMPERATURERed Display 1 & 2 -35 to 75°C3 -35 to 70°C4 -35 to 60°C5 -35 to 50°CGreen Display 1 & 2 -35 to 75°C3 -35 to 65°C4 -35 to 50°C5 -35 to 35°C

IP Rating

IP65

Safety, Standards & Compliance

Compliance Standards

CE ApprovedEN 61326-1 Immunity to Industrial LocationsEmission CISPR 11 Class ASafety requirements for electrical equipment for measurement, control, andlaboratory use:EN 61010-1: General RequirementsEN 61010-2-030: Particular Requirements for Testing and MeasuringCircuits

Hazardous Location Ratings

RoHS CompliantUL Recognized Component: File #E179259UL Listed: File #E137808Type 4X Indoor/Outdoor Enclosure rating (Face only)

Red Lion CUB5RTB0 Miniature Electronic Dual Counter and Rate Indicator 9-28VDC 5 Digit LCD Display

Product Code: CUB5RTB0
