Red Lion 111FX3-SC Unmanaged Industrial Ethernet Switch ANT

Product Code: 111FX3-SC

  • Easy DIN rail mounting
  • High IP67 protection rating
  • Certified for ATEX and IECEx standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Industrial Ethernet Switch
Brand
Red Lion
Series
N - Tron

Electrical

Input Voltage
10-49 VDC (Regulated)

Mechanical

Housing Material
Hardened Metal
Mounting
DIN rail mount (bracket included)

Dimensions & Physical Data

Depth
135.03mm
Height
107.95mm
Weight
0.64kg
Width
60.98mm

Environmental

Operating Temperature
-40°C to 80°C

Communication & Control

Connectors/Input/Output
8x RJ45, 3x SC
Total Ports
11
Fiber Connector Type
SC Connector

Safety, Standards & Compliance

Standards and Approvals
FCC: Title 47, Part 15, Subpart B, Class A; ANSI C63.4; ICES-003 UL /cUL: Class I, Div 2, Groups A, B, C, D and T4 CE: IEC 61000-4-2/3/4/5/6/8/11, EN 61000-6-2/4 Other: ABS Type Approval for Shipboard Applications; GOST-R certified; RoHS compliant

Documents

IPD Product Catalogue V17
