Puls PIC480.481D Power Supply 1PH 100-240VAC 12VDC 10A 480 Watt 21.6 Watt DIN Rail Mount Screw Terminal IP20

Product Code: PIC480.481D

  • Single-phase, 10 A rated current
  • Wide voltage range: 100-240 VAC, 12 VDC
  • High efficiency at 95.7%
  • Compact DIN rail mount design
  • Robust metal construction with IP20 protection
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Supply
Brand
Puls
Series
PIANO

Electrical

Input Voltage
100-240 V AC
Output Current - Nominal
Nom. 10.0A At 48V and an ambient temperature below 55°C Nom. 6.3A At 48V and 70°C ambient temperature Nom. 8.6A At 56V and an ambient temperature below 55°C Nom. 5.4A At 56V and 70°C ambient temperature
Output Power
36W
Output Voltage - Nominal
48V DC
Output Voltage - Range
24V to 28V
Efficiency
94.6 / 95.7% At 120 / 230Vac
Terminal Type
Screw Terminal

Mechanical

Housing Material
Body: Aluminium alloy Cover: zinc-plated steel

Dimensions & Physical Data

Depth
127mm
Height
124mm
Weight
0.81kg
Width
59mm

Environmental

Operating Temperature
-10°C to 70°C
