Puls ML100.100 Power Supply 1PH 110-300VDC 24VDC 4.2A 100 Watt 11.4 Watt DIN Rail Mount Spring Clamp IP20

Product Code: ML100.100

  • Single-phase, 100 W rated power
  • Wide voltage range: 110-300 VDC, 24 VDC
  • High efficiency at 90%
  • Compact design: 73x75x103 mm
  • DIN Rail mounting with IP20 protection
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Supply
Brand
Puls
Series
Mini Line

Electrical

Input Voltage
100-120/220-240 V AC (Auto Select) / 220...375 V DC
Output Current - Nominal
4.2A
Output Power
100W
Output Voltage - Nominal
24.5V DC
Output Voltage - Range
24V to 28V
Efficiency
typ. 90%
Terminal Type
Spring Clamp terminals

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
103mm
Height
75mm
Weight
0.36kg
Width
73mm

Environmental

Operating Temperature
-10°C to 70°C

Documents
