Pfannenberg 23370630000 Patrol Sounder 120 dB(A) 12, 24, 48 VDC 0.88 A IP66

Product Code: 23370630000

  • Operates on 230 VAC/VDC
  • Flashing sounder with red light
  • Metal bezel for durability
  • Long service life of 100,000 hrs
  • Complies with IEC/EN and UL standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Patrol Sounder
Brand
Pfannenberg
Series
PA-20

Electrical

Rated Current (In)
0.88A
Rated Voltage (Ur)
12, 24, 48 VDC
Terminal Type
Screw Terminals

Mechanical

Functionality
Multifunctional Sounds
Housing Colour
Red
Housing Material
PC / ABS blend
Loudness
120 dB(A)
Sound Frequency
2900Hz

Dimensions & Physical Data

Depth
181mm
Height
170mm
Mounting Hole Diameter (mm)
22.3mm
Weight
1.09kg
Width
215mm

Environmental

IP Rating
IP66
Ambient Temperature
-40°C to 55°C

Documents

IPD Product Catalogue V17
