Pfannenberg 23351105000 Flashing Sounder 107 dB(A) 230 VAC 0.07 A IP66

Product Code: 23351105000

  • Compact design: 10 mm width
  • Durable plastic and glass fibre housing
  • Operates in -25 to 80°C range
  • Meets cULus, EN IEC 60947 standards
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Flashing Sounder
Brand
Pfannenberg
Series
PA-X-5-05

Electrical

Rated Current (In)
0.07A
Rated Voltage (Ur)
230V AC
Terminal Type
Screw-Terminals

Mechanical

Functionality
Sounder/flashing light combinations
Housing Colour
Red/RAL 3000
Lamp Colour
Red
Lamp Type
XENON
Loudness
107 dB(A)
Sound Frequency
2900Hz

Dimensions & Physical Data

Depth
81mm
Height
215mm
Mounting Hole Diameter (mm)
22.3mm
Weight
0.983kg
Width
164mm

Environmental

IP Rating
IP66
Ambient Temperature
-40°C to 55°C

Documents

IPD Product Catalogue V17
