Pfannenberg 23350630001 Patrol Sounder 107 dB(A) 12, 24, 48 VDC 0.08 A IP66

Product Code: 23350630001

  • Operates on 230V AC/DC at 3mA
  • Blue illuminated buzzer
  • Wide temp range: -30 to 70°C
  • Long service life of 100,000 hrs
  • Meets UL, IEC, and CSA standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Patrol Sounder
Brand
Pfannenberg
Series
PA-5

Electrical

Rated Current (In)
0.08A
Rated Voltage (Ur)
12, 24, 48 VDC
Terminal Type
Screw Terminals

Mechanical

Functionality
Multifunctional Sounds
Housing Colour
Red
Housing Material
PC / ABS blend
Loudness
107 dB(A)
Sound Frequency
2900Hz

Dimensions & Physical Data

Depth
132mm
Height
135mm
Mounting Hole Diameter (mm)
22.3mm
Weight
0.643kg
Width
164mm

Environmental

IP Rating
IP66
Ambient Temperature
-40°C to 55°C

Documents

IPD Product Catalogue V17
