Pfannenberg 23311105000 Flashing Sounder 105 dB(A) 230 VAC 0.02 A IP66

Product Code: 23311105000

  • Illuminated patrol sounder with white glass dome
  • Durable aluminium front ring, IP65 rated
  • Operates in -25 to 75°C temperature range
  • Vibration resistance from 10-150 Hz
  • Flange mount with 22.3 mm hole diameter
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Flashing Sounder
Brand
Pfannenberg
Series
PA-X-1-05

Electrical

Rated Current (In)
0.02A
Rated Voltage (Ur)
230V AC
Terminal Type
Screw-Terminals

Mechanical

Functionality
Flashing Light
Housing Colour
Red/RAL 3000
Lamp Colour
Red
Lamp Type
XENON
Loudness
105 dB(A)

Dimensions & Physical Data

Depth
81mm
Height
173mm
Mounting Hole Diameter (mm)
22.3mm
Weight
0.73kg
Width
110mm

Environmental

IP Rating
IP66
Ambient Temperature
-40°C to 55°C

Documents

IPD Product Catalogue V17
