Pfannenberg 23111100001 Sounder 114 dB(A) 230 V 0.06 A IP67

Product Code: 23111100001

  • Operates at 12 VAC/VDC, 20 mA
  • Illuminated with red BA9S lamp
  • Metal bezel for durability
  • Wide temp range: -30 to 70°C
  • Long service life of 100,000 hrs
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Sounder
Brand
Pfannenberg
Series
DS 10

Electrical

Rated Current (In)
0.06A
Rated Voltage (Ur)
230V
Terminal Type
Screw Terminals

Mechanical

Functionality
Multifunctional Sounds
Housing Colour
Red
Housing Material
Die-Cast Aluminium GD-AI Si12 Cu
Loudness
114 dB(A)
Sound Frequency
2400Hz

Dimensions & Physical Data

Depth
143mm
Height
133mm
Mounting Hole Diameter (mm)
22.3mm
Weight
2.15kg
Width
170mm

Environmental

IP Rating
IP67
Ambient Temperature
-40°C to 55°C
