Pfannenberg 23111100000 Sounder 114 dB(A) 230 V 0.06 A IP66/67

Product Code: 23111100000

  • Operates at 12 VAC/VDC, 20 mA
  • Illuminated with blue lamp
  • Metal bezel for durability
  • Service life of 100,000 hrs
  • Wide temp range: -30 to 70°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Sounder
Brand
Pfannenberg
Series
DS 10

Electrical

Rated Current (In)
0.06A
Rated Voltage (Ur)
230V
Terminal Type
Screw Terminals

Mechanical

Functionality
Multifunctional Sounds
Housing Colour
Red
Housing Material
Metal
Loudness
114 dB(A)
Sound Frequency
2400Hz

Dimensions & Physical Data

Depth
143mm
Height
133.5mm
Mounting Hole Diameter (mm)
22.3mm
Weight
2.15kg
Width
133.5mm

Environmental

IP Rating
IP66/67
Ambient Temperature
-40°C to 55°C

Documents

IPD Product Catalogue V17
