PFANNENBERG COOLING UNIT 400 2~V 1.5kW RAL7035 IP54 DTI 6301

Product Code: 13896319055

  • Cooling capacity of 1500 W for efficient performance
  • Operates at 400 VAC with a frequency of 50/60 Hz
  • IP54 protection for reliable safety in various conditions
  • Compact design: 485mm W x 1536mm H x 50mm D
  • Noise level below 62 dBA for quieter operation
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Cooling Unit
Brand
Pfannenberg
Series
DTI

Electrical

Power Consumption
786/863W
Rated Current (In)
3.24 / 2.63A
Rated Frequency
50Hz / 60Hz
Rated Voltage (Ur)
400V
Cooling Capacity
1500 W

Mechanical

Colour
RAL 7035 (Light Grey)
Material
Galvanised sheet steel housing, powder-coated cover
Mounting
DTI – Door/Side, Partially Recessed Mounting
Unimpeded Airflow-Internal
935 m³/h
Cover Material
Electrostatically powder-coated steel

Dimensions & Physical Data

Depth
158mm
Height
1536mm
Weight
55kg
Width
485mm

Environmental

Operating Temperature
15°C to 55°C
IP Rating
IP54 / IP34
Ambient Temperature
15°C to 55°C
Noise Level
< 62 dB(A)

Safety, Standards & Compliance

Standards and Approvals
EN 60529 (IP54/IP34)

Documents

IPD Product Catalogue V17
