Panasonic EX-F61 Leak Detection Sensor 12-24VDC NPN-Output

Product Code: EX-F61

  • Operates on 12-24 VDC, 15 mA current
  • Durable PFA body with IP67 protection
  • Quick response time under 50 ms
  • Infrared LED for reliable detection
  • CE, RoHS, UL recognized standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Leak Detection Sensor
Brand
Panasonic
Series
EX - 60

Electrical

Sensing Type
Leak detection
Type of Switching Output
NPN-Output
Electrical Connection
Cable
Light Source
Infrared LED (non-modulated)
Rated Voltage (Ur)
12V to 24V DC

Mechanical

Material
Enclosure: PFA

Dimensions & Physical Data

Depth
9mm
Height
19mm
Width
26mm
Cable Length
3m

Environmental

Operating Temperature
-10°C to 60°C
IP Rating
IP67 (IEC)

Documents

IPD Product Catalogue V17
