Panasonic AIG32TQ02DR Programmable Display 115.2 mm W x 86.4 mm H 24VDC

Product Code: AIG32TQ02DR

  • Operates at 24 VDC for reliable performance
  • Suitable for temperatures from 0 to 50°C
  • Display size: 115.2mm (W) x 86.4mm (H)
  • Black and white display with white LED backlight
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Programmable Display
Brand
Panasonic
Series
GT

Electrical

Channel Isolation
Transformer-isolated power supply
Input Ratings
21.6 to 26.4 V DC
Power Consumption
7.2W
Supply Voltage
24V DC
Touch Type
Analog touch

Mechanical

Display Colour/Type
4096 colors

Dimensions & Physical Data

Depth
39.1mm
Height
128.8mm
Width
163.2mm
Panel Cut-Out Size
150.2mm x 119mm
Display Size
5.7 inch

Environmental

Storage Temperature
-20°C to 60°C
Operating Temperature
0°C to 50°C
IP Rating
IP67

Communication & Control

Serial Ports
1
USB Port
1
Supported Serial Protocols
Panasonic FP Series, General-purpose Serial, and Modbus RTU

Safety, Standards & Compliance

Certifications / Approvals
CE (EMC/RoHS), UKCA, UL/c-UL (File E96300, UL 508)

Accessories & Additional Information

Development Software
Terminal GTWIN (Ver. 2 or Ver. 3)
