Specifications

Product Type

Control Unit

Brand

Panasonic

Series

FPX

Analog Resolution 14 bit	Channel Isolation Photocoupler	No. of Analog Inputs 8
No. of Analog Outputs 6	No. of Digital Inputs 8	No. of Digital Outputs 6
Output Ratings 0.5 A	Input Ratings 24 V DC	Input Type NPN
Output Type Transistor Output (NPN)	Power Consumption <=23W	Supply Voltage 100V to 240V AC
Terminal Type Screw Terminal

Depth

82mm

Height

90mm

Width

86mm

Storage Temperature

-40°C to 70°C

Operating Temperature

0°C to 55°C

Expandable Communications Yes	Fieldbus Interface 1	Serial Ports 1
USB Port 1	Supported Serial Protocols MEWTOCOL COM (computer link) Master/Slave General communication PLC link MODBUS RTU Master/Slave

Hazardous Location Ratings

Level of Contamination 2

Certifications / Approvals

EMC directive: EN 61131-2 (directive concerning emission, immunity and low voltage)

Development Software

Control FPWIN Pro7/FPWIN GR7

Panasonic AFPXHC14T Programmable Controller 100-240VAC 14 Analogue Outputs 8 Digital Inputs 6 Digital Outputs
