Novaris SSP1-20-50-275 Surge Protector 15kA 1 PH 20A 230VAC TS35 Panel Mounting Metal IP20

Product Code: SSP1-20-50-275

  • Protects against surges with L-N, L-PE, N-PE modes
  • Quick response time: <5 ns (L-N), <100 ns (N-PE)
  • LED status display for easy monitoring
  • Compact size: 54x69x95 mm; fits TS35 DIN rail
  • Complies with IEC, AS/NZS, UL standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Protector
Brand
Novaris
Series
SSP1
Application
Economic protection to AC power circuits

Electrical

Max. Discharge Current Imax (8/20µs)
50kA (L-N)60kA (N-PE)
Nominal Discharge Current Inom (8/20µs)
20kA (L-N)50kA (N-PE)

Mechanical

Terminal Size
16mm²
Connection/Termination
Series

Dimensions & Physical Data

Depth
69mm
Height
95mm
Width
54mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
