Novaris SLM-18 Multiline Signal Line Protector 20kA 16VDC Panel Mount 128mm W 42mm D 80mm H IP20

Product Code: SLM-18

  • Handles up to 20 kA current
  • IP20 protection for panel mounting
  • Operates in -40 to 85°C range
  • Complies with IEC, ITU-T, AS/NZS standards
  • Protects 12 lines in transverse & common modes
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Multi - Circuit Signal Line Protectors
Brand
Novaris
Series
SLM
Application
Signal, Process Control, Input / Output / Comms

Electrical

No. of Lines/Pairs
12
Voltage Protection Level Up
20V
Max. Discharge Current Imax (8/20µs)
20kA
Max. Continuous Operating Voltage
11 V AC / 16 V DC

Mechanical

Terminal Size
2.5 mm2

Dimensions & Physical Data

Depth
130mm
Height
60mm
Width
80mm

Environmental

Operating Temperature
-40°C to 85°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
