Novaris SL18-G Slimline Signal Line Protector 5kA 10kA 16VDC TS35 102mm H IP20

Product Code: SL18-G

  • Protects with 5 kA per line, 10 kA common mode.
  • Compact design: 7.5 mm width.
  • Easy TS35 DIN rail mounting.
  • Fast response time under 5 ns.
  • Operates in -55 to 70°C range.
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Protector
Brand
Novaris
Series
SL
Application
PLCs, fire and security systems,telecommunications and telemetry systems, railway signalling, SCADA andother industrial monitoring and control equipment

Electrical

Max. Discharge Current Imax (8/20µs)
5kA

Mechanical

Terminal Size
2.5mm²
Connection/Termination
Series

Dimensions & Physical Data

Depth
68mm
Height
102mm
Width
7mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
