Novaris SFD1-6-3-30-C Combined Power and Signal Protector 1 PH 3kA 20kA 24VAC 50/60Hz TS35 18mm W 70mm D 116mm H IP20

Product Code: SFD1-6-3-30-C

  • Surge protection for 24 VAC systems
  • Handles currents of 3 kA, 20 kA
  • Compact design: 18mm width
  • Easy TS35 DIN Rail mounting
  • Operates in -40 to 85°C range
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Sfd1 Combined Cctv Protection
Brand
Novaris
Series
SFD-C
Application
Signal, Network and CCTV

Electrical

Max. Backup Fuse
6:00 AM
Max. Load Current
6:00 AM
No. of Phases
1
Modes of Protection
L-N, L-PE, N-PE
Nominal Voltage
24 V AC
Voltage Protection Level Up
100 V
Max. Discharge Current Imax (8/20µs)
3 kA
Short Circuit Current Rating
3 kA
Nominal Discharge Current Inom (8/20µs)
1 kA
Max. Continuous Operating Voltage
30 V AC

Mechanical

Terminal Size
2.5 mm2

Dimensions & Physical Data

Depth
115 mm
Height
69 mm
Width
18 mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20
