Novaris SFD1-6-10-275 Surge Filter 1 PH 6A 230VAC TS35 Panel Mounting Metal IP20

Product Code: SFD1-6-10-275

  • 230 VAC, 6 A single-phase surge filter
  • LED status display for easy monitoring
  • IP20 protection; TS35 DIN rail/panel mount
  • Operates in -40 to 70°C with metal build
  • Complies with IEC, AS/NZS, UL, IEEE standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Diverter
Brand
Novaris
Series
SFD1
Application
Critical installations, sensitive electronics and computer equipment with single phase loads up to 32 A

Electrical

Max. Backup Fuse
6A
No. of Poles (Total)
1
Nominal Voltage
230V
Voltage Protection Level Up
<1200V
Max. Discharge Current Imax (8/20µs)
10kA
Nominal Discharge Current Inom (8/20µs)
4kA (L-N)4kA (N-PE)
Max. Continuous Operating Voltage
275VAC (L-N)255VAC (N-PE)

Mechanical

Terminal Size
2.5 mm²

Dimensions & Physical Data

Depth
115mm
Height
69mm
Width
18mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
