Novaris SD3-150-275 Surge Diverter 19kA 3 PH 150kA 230VAC Mount Aluminium IP20

Product Code: SD3-150-275

  • Rated for 230 VAC, 150 kA (L-N) current
  • Digital display for easy monitoring
  • IP20 protection and panel mounting
  • Aluminium build, compact 200x80x200 mm
  • Fast response time of <25 ns (L-N)
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Diverter
Brand
Novaris
Series
SD3
Application
Industrial and commercial main switchboards

Electrical

Max. Backup Fuse
80A
No. of Poles (Total)
3
Nominal Voltage
230V
Voltage Protection Level Up
<750V
Max. Discharge Current Imax (8/20µs)
150kA

Dimensions & Physical Data

Depth
80mm
Height
200mm
Width
200mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
