Novaris SD3-150-275-N Surge Diverter 19kA 30kA 3 PH 150kA 150kA 230VAC Mount Aluminium IP20

Product Code: SD3-150-275-N

  • Surge protection for 230 VAC systems
  • Handles up to 150 kA current
  • Digital display for easy monitoring
  • Complies with IEC, AS/NZS, UL standards
  • Operates in -40 to 70°C range
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Diverter
Brand
Novaris
Series
SD3
Application
Industrial and commercial main switchboards

Electrical

Max. Backup Fuse
100A
No. of Poles (Total)
3
Nominal Voltage
230V
Voltage Protection Level Up
<750V
Max. Discharge Current Imax (8/20µs)
150kA

Dimensions & Physical Data

Depth
80mm
Height
200mm
Width
200mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
