Novaris SD1-150-275-N Surge Diverter 19kA 30kA 1 PH 150kA 150kA 230VAC TS35 IP20

Product Code: SD1-150-275-N

  • Surge protection for 230 VAC systems
  • Handles up to 150 kA current
  • Compact design, IP20 rated
  • Digital display for easy monitoring
  • Mounts on TS35 DIN rail
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Multimov Surge Diverters
Brand
Novaris
Series
SD1
Application
Power, Main Switchboards, Commercial and Industrial

Electrical

Lightning Impulse Current Iimp (10/350µs)
19kA
Max. Backup Fuse
80A
Nominal Voltage
230V AC
Voltage Protection Level Up
1500V
Max. Discharge Current Imax (8/20µs)
150kA
Short Circuit Current Rating
75kA
Alarm Contact
SPDT power and thermal failure
Nominal Discharge Current Inom (8/20µs)
60kA
Max. Continuous Operating Voltage
275 V AC

Mechanical

Terminal Size
16 mm2

Dimensions & Physical Data

Depth
141mm
Height
69mm
Width
54mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
