Novaris RJ45-16CAT6 Network Protector 1kA 2kA 5kA 10kA 4VAC RJ45 Socket Rack Mount 88mm H Steel IP20

Product Code: RJ45-16CAT6

  • Rated for 5 kA per line, 10 kA common mode
  • RJ45 socket connection, easy rack mount
  • Operates in -40 to 70°C, IP20 protection
  • Fast response time <5 ns
  • Compliance with IEC, UL, and AS standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Network Protectors
Brand
Novaris
Series
RJ45-CAT6
Application
Protection of equipment connected to twisted pair network cabling systems

Electrical

No. of Lines/Pairs
16 x RJ45 / 4 pairs & shield
Voltage Protection Level Up
20V @ 1kV/ µs
Max. Discharge Current Imax (8/20µs)
5kA
Max. Continuous Operating Voltage
4 V AC / 6 V DC

Mechanical

Terminal Size
RJ45 Socket

Dimensions & Physical Data

Depth
483mm
Height
88mm
Width
20mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
