Novaris NSP3-50-275 Surge Diverter W/Replaceable Module 3 PH 50kA 275VAC Plastic

Product Code: NSP3-50-275

  • Rated voltage of 275 VAC for optimal performance
  • Handles up to 50 kA current effectively
  • Suitable for 3-phase systems
  • Durable plastic construction
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Nsp Surge Diverter
Brand
Novaris
Series
NSP3
Application
Power, Distribution Boards and Domestic MSB, Modular and Domestic

Electrical

Lightning Impulse Current Iimp (10/350µs)
7.5kA
Max. Backup Fuse
32A
Nominal Voltage
230V AC
Voltage Protection Level Up
1200V
Max. Discharge Current Imax (8/20µs)
50kA
Short Circuit Current Rating
25kA
Nominal Discharge Current Inom (8/20µs)
20kA
Max. Continuous Operating Voltage
275 V AC

Mechanical

Terminal Size
35 mm2

Dimensions & Physical Data

Depth
69mm
Height
90mm
Width
54mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
