Novaris MPP-VDSL Telephone Line Protector With Spacer and Screw Adaptor 1.25kA 5kA 200VDC 26mm H

Product Code: MPP-VDSL

  • Suitable for 200 VDC applications
  • Handles up to 5 kA per line
  • Compact size: 90x26x26 mm
  • Voltage protection level under 950 V
  • Lightning impulse current of 1.25 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Modular Plug Protector Vdsl
Brand
Novaris
Series
MPP
Application
Signal, Network and CCTV

Electrical

Lightning Impulse Current Iimp (10/350µs)
1.25kA
No. of Lines/Pairs
1 pair
Voltage Protection Level Up
950V
Max. Discharge Current Imax (8/20µs)
5kA
Max. Continuous Operating Voltage
162 V AC / 230 V DC

Dimensions & Physical Data

Depth
80mm
Height
28mm
Width
27mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
