Novaris KP1-T Telephone Protector 10kA 200VDC KRONE LSA-PLUS 21mm W 9.5mm D 53.3mm H ABS Black EDM IP20

Product Code: KP1-T

  • Rated for 200 VDC, 10 kA current
  • Compact size: 21mm x 53.3mm x 9.5mm
  • Fast response time under 5 ns
  • Operates in -40 to 85°C range
  • Compliance with IEC, UL, ITU-T standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Krone Protector
Brand
Novaris
Series
KP KRONE-LSA
Application
Signal, Network and CCTV

Electrical

No. of Lines/Pairs
1 pair
Voltage Protection Level Up
220V
Max. Discharge Current Imax (8/20µs)
5kA
Max. Continuous Operating Voltage
140 V AC / 200 V DC

Dimensions & Physical Data

Depth
21mm
Height
54mm
Width
10mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
