Novaris IS-LCP-18 Load Cell Protector 0.25kA 18VDC 116mm W 56mm D 65mm H Aluminium IP65

Product Code: IS-LCP-18

  • Surge protector for 18 VDC systems
  • IP65-rated for robust protection
  • Operates in -40 to 85°C environments
  • Aluminium construction, weighs 600 g
  • Protects with transverse & common modes
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Is - Lcp Intrinsically Safe Load Cell Protector
Brand
Novaris
Series
IS-LCP
Application
Signal, Process Control Hazardous Areas, Loadcells

Electrical

No. of Lines/Pairs
4 or 6
Voltage Protection Level Up
45V
Max. Discharge Current Imax (8/20µs)
0.25kA
Max. Continuous Operating Voltage
12 V AC / 18 V DC

Mechanical

Terminal Size
2.5 mm2

Dimensions & Physical Data

Depth
160mm
Height
56mm
Width
66mm

Environmental

Operating Temperature
-40°C to 85°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
