Novaris DB25-RS232 DB Protector 2.5kA 36V Female Male 56mm W 63mm D 17mm H IP20

Product Code: DB25-RS232

  • Rated for 36V and 2.5kA current
  • Compact size: 56mm x 17mm x 63mm
  • Operates in -40 to 85°C range
  • Complies with IEC, ITU-T, AS/NZS, IEEE, UL standards
  • RS232 communication interface
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Rs Serial Port Protectors
Brand
Novaris
Series
DB
Application
Signal, Network and CCTV

Electrical

No. of Lines/Pairs
8
Voltage Protection Level Up
45V
Max. Discharge Current Imax (8/20µs)
0.25kA
Max. Continuous Operating Voltage
25 V AC / 36 V DC

Dimensions & Physical Data

Depth
63mm
Height
16mm
Width
55mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
