Novaris CS-FF-230-3-M SMA RF Protector 20kA 50kA 230VDC 3GHz S-Type Female 90 deg Mount Bracket Mount 25mm H Brass IP55

Product Code: CS-FF-230-3-M

  • Protects against surges up to 50 kA
  • Suitable for 230 VDC systems
  • IP55-rated for dust and water resistance
  • Operates in -40 to 85°C temperature range
  • Complies with IEC, UL, ITU-T standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Rf Equipment Protector
Brand
Novaris
Series
CS
Application
Signal, RF Protection

Electrical

Max. Working Frequency
3 GHz
Power Rating
150W
Sparkover Voltage
0.23kV DC
Voltage Protection Level Up
820V
Max. Discharge Current Imax (8/20µs)
20kA

Mechanical

Connection Orientation
F/F
Connection/Termination
S-type

Dimensions & Physical Data

Depth
48mm
Height
25mm
Width
25mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
