Mersen US6J1 Fuse Holder 60A 600VAC/DC 30sq-mm Cable Entry 27mm Dia x 60mm L Fuse For: AJT/A4J

Product Code: US6J1

  • Holds Class J fuses securely
  • Supports 60 A, 600 VAC/VDC
  • IP20 protection ensures safety
  • Compatible with AJT/A4J fuses
  • Fits 27 mm x 60 mm fuse size
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Holder
Brand
Mersen
Series
US6J UltraSafe Class J
Application
600 V motors, transformers, lighting, heating, control circuits and general loads; non-load disconnect

Electrical

Breaking Capacity
200kA SCCR
Rated Current (In)
60A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC/DC

Mechanical

Indicators
without indicator
Material
Polyamide body; tin-plated copper contacts
Mounting
35 mm DIN rail
Size Code
Class J / 27 x 60
Connection/Termination
Pressure plate / screw terminal
Fuse Holder
AJT, A4J, HSJ Class J fuses

Dimensions & Physical Data

Depth
115mm overall
Length
122mm
Weight
0.272kg
Width
40mm

Environmental

IP Rating
IP20

Safety, Standards & Compliance

Standards and Approvals
UL 4248-8; IEC 60269-1; IEC 60947-3
