Mersen SBS7 Fast-Acting Midget Fuse 7A 600VAC 0.41 in Dia 1.38 in L 100kA Interrupt Ferrule

Product Code: SBS7

  • Rated for 7 A and 600 VAC
  • Compact size: 1.38 in length
  • High interrupt rating of 100 kA
  • Ferrule terminals with tin-plated copper
  • GMG body and insulation material
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
SBS
Application
Control circuits, lighting ballasts, meter circuits, electronic circuits and general purpose protection

Electrical

Breaking Capacity
100 kA
Rated Current (In)
7 A
Rated Frequency
50/60 Hz
Rated Voltage (Ur)
600 V AC
Speed Class
Fast-Acting

Mechanical

Body Style
Cylindrical
Indicators
No indicator
Material
Body: Fiberglass
Mounting
Clip
Size Code
13/32 x 1 3/8
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
34.93 mm
Weight
0.0073 kg (Approx.)
Width
Ø10.32 mm

Safety, Standards & Compliance

Standards and Approvals
UL Listed to UL 248-14 (File E33925), CSA Certified to C22.2 No. 248.14
