Mersen SBS2 Fast-Acting Midget Fuse 2A 600VAC 0.41 in Dia 1.38 in L 100kA Interrupt Ferrule

Product Code: SBS2

  • Rated for 600 VAC, 2 A, and 50/60 Hz
  • High interrupt rating of 100 kA
  • Compact size with a length of 1.38 in
  • Durable GMG body and insulation material
  • Easy clip mounting system
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Midget Fuse
Brand
Mersen
Series
SBS
Application
Control circuits, lighting ballasts, meter circuits and electronic circuits

Electrical

Breaking Capacity
100 kA RMS
Rated Current (In)
2 A
Rated Frequency
50/60 Hz
Rated Voltage (Ur)
600 V AC
Speed Class
Fast-acting

Mechanical

Body Style
Ferrule / cylindrical
Indicators
No
Material
Fiberglass body
Size Code
35 x 10
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
35 mm
Weight
0.0073 kg
Width
Ø 10 mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-14, CSA C22.2 No. 248.14

Documents

IPD Product Catalogue V17
