Mersen SBS1.5 Fast-Acting Midget Fuse 1.5A 600VAC 0.41 in Dia 1.38 in L 100kA Interrupt Ferrule

Product Code: SBS1.5

  • Rated for 1.5 A current
  • Handles up to 600 VAC
  • Clip mounting for easy install
  • High interrupt rating of 100 kA
  • Tin plated copper terminals
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Midget Fuse
Brand
Mersen
Series
SBS
Application
Control circuits, lighting ballasts, meter circuits and electronic circuits

Electrical

Breaking Capacity
100kA RMS
Rated Current (In)
1.5A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC
Speed Class
Fast-acting

Mechanical

Body Style
Ferrule / cylindrical
Indicators
No
Material
Fiberglass body
Size Code
35 x 10
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
35mm
Weight
0.0073kg
Width
Ø 10mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-14, CSA C22.2 No. 248.14

Documents

IPD Product Catalogue V17
