Mersen OTS60 Fast-Acting General Purpose Fuse 60A 600/300VAC/DC Class K5 1.06 in Dia x 5.5 in L Ferrule Terminal

Product Code: OTS60

  • Rated for 60 A current capacity
  • Supports 600/300 VAC/VDC voltage
  • Clip mounting for easy installation
  • High breaking capacity of 50 kA
  • Durable Poly Tube body material
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Class K5 Fast - Acting Fuse
Brand
Mersen
Series
OTS
Application
General purpose branch-circuit and equipment protection

Electrical

Utilization Category
Class K5
Breaking Capacity
50kA
Rated Current (In)
60A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 300V DC
Speed Class
Fast acting

Mechanical

Body Style
Cylindrical / ferrule
Indicators
without indicator
Mounting
Clip-in fuse holder
Size Code
27 x 139
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
139mm
Weight
0.0975kg
Width
Ø 27mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-9; CSA C22.2 No. 248.9

Documents

IPD Product Catalogue V17
