Mersen OTS40 Fast-Acting General Purpose Fuse 40A 600/300VAC/DC Class K5 1.06 in Dia x 5.5 in L Ferrule Terminal

Product Code: OTS40

  • 40A rated current for reliable performance
  • Supports 600/300 VAC/VDC applications
  • High breaking capacity of 50 kA
  • Compact design: 1.06 in Dia x 5.5 in L
  • Easy clip mounting system
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Class K5 Fast - Acting Fuse
Brand
Mersen
Series
OTS
Application
General purpose branch-circuit and equipment protection

Electrical

Utilization Category
Class K5
Breaking Capacity
50kA
Rated Current (In)
40A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 300V DC
Speed Class
Fast acting

Mechanical

Body Style
Cylindrical / ferrule
Indicators
without indicator
Mounting
Clip-in fuse holder
Size Code
27 x 139
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
139mm
Weight
0.0975kg
Width
Ø 27mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-9; CSA C22.2 No. 248.9
