Mersen OTS225 Fast-Acting General Purpose Fuse 225A 600/300VAC/DC Class K5 2.56 in Dia x 11.63 in L Blade Terminal

Product Code: OTS225

  • UL North American standard
  • Handles 225 A current
  • Voltage rating: 600/300 VAC/VDC
  • High breaking capacity of 50 kA
  • Durable poly tube body
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
OTS
Application
Residential and small commercial installations

Electrical

Breaking Capacity
50kA AC, 20kA DC
Rated Current (In)
225A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
600V AC / 300V DC
Speed Class
Fast-acting

Mechanical

Body Style
Ferrule
Material
Body: Poly tube, Terminal: Tin-Plated Copper
Mounting
Clip

Dimensions & Physical Data

Length
219mm
Weight
1.456kg (Approx.)
Width
Ø 53mm
