Mersen OTM20 Fast-Acting Midget Fuse 20A 250VAC 0.41 in Dia 1.5 in L 10kA Interrupt Ferrule

Product Code: OTM20

  • Rated for 20 A, 250 VAC
  • Compact size: 1.5 in length
  • High interrupt rating: 10 kA
  • Ferrule terminal with tin-plated copper
  • Suitable for 50/60 Hz applications
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Midget Fast - Acting Fuse
Brand
Mersen
Series
OTM Midget Fast-Acting
Application
Supplementary / general-purpose circuit protection

Electrical

Utilization Category
Fast acting
Breaking Capacity
10kA
Rated Current (In)
20A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
250V AC
Speed Class
Fast acting

Mechanical

Body Style
Cylindrical / ferrule
Indicators
without indicator
Mounting
Clip-in fuse holder
Size Code
10 x 38
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
38mm
Weight
0.0054kg
Width
Ø 10mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-14; CSA C22.2 No. 248.14

Documents

IPD Product Catalogue V17
