Mersen OT450 Fast-Acting General Purpose Fuse 450A 250VAC/DC Class K5 2.56 in Dia x 10.38 in L Blade Terminal

Product Code: OT450

  • Rated for 450 A, 250 VAC/VDC
  • High breaking capacity of 50 kA
  • Compact size: 2.56 in Dia x 10.38 in L
  • Blade terminal with tin-plated copper
  • Durable poly tube body and insulation
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Class K5 Fast - Acting Fuse
Brand
Mersen
Series
OT
Application
General purpose branch-circuit and equipment protection

Electrical

Utilization Category
Class K5
Breaking Capacity
50kA
Rated Current (In)
450A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
250V AC/DC
Speed Class
Fast acting

Mechanical

Body Style
Blade type
Indicators
without indicator
Mounting
Blade / bolted mounting
Size Code
Class K5 blade
Connection/Termination
Blade terminals

Safety, Standards & Compliance

Standards and Approvals
UL 248-9; CSA C22.2 No. 248.9
