Mersen OT400 Fast-Acting General Purpose Fuse 400A 250VAC/DC Class K5 2.06 in Dia x 8.63 in L Blade Terminal

Product Code: OT400

  • Handles 400 A at 250 VAC/VDC
  • Supports clip mounting
  • Class K5 with 50 kA breaking capacity
  • Tin plated copper blade terminals
  • Poly tube body for durability
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
OT
Application
Feeders, Branch circuit, Residential and small commercial installations

Electrical

Breaking Capacity
50kA
Rated Current (In)
400A
Rated Voltage (Ur)
250V AC
Speed Class
Fast-acting

Mechanical

Body Style
Cylindrical
Material
Fiber body, metal caps
Connection/Termination
Blade

Dimensions & Physical Data

Length
219mm
Width
Ø 53mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-9, UL, CSA, RoHS

Documents

IPD Product Catalogue V17
