Mersen OT350 Fast-Acting General Purpose Fuse 350A 250VAC/DC Class K5 2.06 in Dia x 8.63 in L Blade Terminal

Product Code: OT350

  • 350 A rated current for robust performance
  • Supports 250 VAC/VDC applications
  • High breaking capacity of 50 kA
  • Compact design: 2.06 in Dia x 8.63 in L
  • Blade terminals with tin-plated copper
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
OT
Application
Feeders, Branch circuit, Residential and small commercial installations

Electrical

Breaking Capacity
50kA
Rated Current (In)
350A
Rated Voltage (Ur)
250V AC
Speed Class
Fast-acting

Mechanical

Body Style
Cylindrical
Material
Fiber body, metal caps
Connection/Termination
Blade

Dimensions & Physical Data

Length
219mm
Width
Ø 53mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-9, UL, CSA, RoHS
