Mersen OT100 Fast-Acting General Purpose Fuse 100A 250VAC/DC Class K5 1.06 in Dia x 5.88 in L Blade Terminal

Product Code: OT100

  • Rated for 100 A, 250 VAC/VDC
  • High breaking capacity of 50 kA
  • Compact size: 1.06 in Dia x 5.88 in L
  • Durable poly tube body material
  • Blade terminals with tin-plated copper
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
OT
Application
Feeders, Branch circuit, Residential and small commercial installations

Electrical

Breaking Capacity
50kA
Rated Current (In)
100A
Rated Voltage (Ur)
250V AC
Speed Class
Fast-acting

Mechanical

Body Style
Cylindrical
Material
Fiber body, metal caps
Connection/Termination
Blade

Dimensions & Physical Data

Length
181mm
Weight
0.1179kg (Approx.)
Width
Ø 27mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-9, UL, CSA, RoHS

Documents

IPD Product Catalogue V17
